Wrap Around Labeling Machine



The YD-R Series wrap around labeling machine is a rotary hot melt glue labeler that can handle round bottle packaging shapes and perform wrap-around labeling. Depending on actual application requirements and variations in bottle sizes and label specifications, this round label applicator offers a choice of multiple tool platforms, which determines the possible production capacity and enable diverse functions. The wrap around labeling machine comes with 6-, 8-, 12-, 16- or 20-platform rotary tool base depending on the speed requirements and number of label applicators.



The wrap around labeling machine for bottles operates at the impressive speed range of 130 to 460 containers per minute. (Depending upon the label length). It it suitable for bottles with diameters ranging from 40mm to 100mm round shape bottle labeling application as mineral water bottles, drink bottles, glass bottles, sanitizer bottles, etc.



Model	YD-0604R	YD-0806R	YD-1210R	YD-1616R	YD-2024R
Container Shape	Metal, plastic and glass round containers
Container Dimension	Round: Diameter Ø40~Ø100mm / Height 50~300mm (Standard version)
Label Types	OPP/BOPP packing film, PVC film, PET film, Paper plastic composite film, paper labels
Labeling Type	Wrap-around labeling
Rotary base	6-platform rotary base	8-platform rotary base	12-platform rotary base	16-platform rotary base	20-platform rotary base
Max. Labeling speed	Up to 8000 BPH	Up to 10000 BPH	Up to 15000 BPH	Up to 24000 BPH	Up to 28000
Container Height	50~300mm	50~300mm	50~300mm	50~300mm	50~300mm
Container Diameter	Ø40~Ø100mm	Ø40~Ø100mm	Ø40~Ø100mm	Ø40~Ø70mm	Ø40~Ø70mm
Labeling Accuracy	±1mm
Label Size	Length 130~330mm / Width 20~145mm
Max. Width of Label	140mm (Options for extended label widths are available upon request.)
Max. Roll Diameter	Ø600mm
Core Diameter	Ø152mm
Max. Label Feeding Speed	150m/min.
Adhesive Type	Hot melt glue. The adhesive is applied only to the leading and trailing edges of the label.
Gluing Temperature	120~160°C
Speed Control	Continuously variable speed control
Conveyor Belt Dimension	Length 3500mm / Width 100mm / Height 1100mm±30mm
Power	AC 380 50/60Hz (three-phase)
Max. Power Consumption	10~15kW
Gas Consumption	6KG-8L/min
Mechanical Dimension	2420mm(L)x2500mm(W)x2050mm(H)
Machine Weight	About 3000kg



* Production capacity is for reference only and may vary depending on product specifications.
* The rotary base platform has a height adjustment range of ±50mm.





The YD Pack wrap around labeling machine offers numerous advantages, including:

• Increased Efficiency: The hot melt glue labeler applies labels quickly and accurately, significantly boosting production speed.
• Cost-Effectiveness: YD Pack's fully automatic rotary hot melt glue labeling machine reduces labor costs and minimizes errors.
• Consistency: Ensures uniform label application for a professional product appearance.
• Flexibility: Handles various bottle sizes to meet diverse labeling requirements.
• Reliability: Built with high-quality, durable components for long-term performance stability.





Our advanced labeling machine is engineered to handle a wide range of production requirements across multiple sectors:

Compatible Container Shapes



Application Industries



✓ Production Flexibility – Adapt to different products and labels without downtime.

✓ Future-Ready Technology – Industry 4.0 compatible with data logging capabilities.

✓ Lower Maintenance Costs – Fewer moving parts extend service intervals.

✓ Customizable with additional modules like print-and-apply or variable data labeling upon request.

Why This Matters for Your Production?

• Material Flexibility: Switch between container types without downtime
• Brand Consistency: Professional-grade labeling for any packaging design
• Industry Compliance: Meets standards for food, chemical, and consumer goods
• Custom configurations available for unique container shapes or specialized label requirements.





Few products truly follow a "one-size-fits-all" approach, particularly in bottle labeling machinery. The most effective wrap around labeling machine are custom-designed to meet specific customer requirements. These needs vary significantly - from label materials to container shapes and surface textures - necessitating tailored solutions for each application.



YD Pack follows this labeling project process to develop your customized labeling system:





When you choose a custom wrap around labeling machine from YD Pack, we focus on your unique current needs. To fully capitalize on market opportunities, you need flexibility to adapt to changes like new product shapes and sizes. From the moment it leaves our factory, every YD Pack bottle labeling machine is designed for future adjustments. This allows easy adaptation of our labeling systems to your evolving requirements. Most upgrades can be implemented quickly and easily without investing in entirely new equipment.
